XU-1 diff codes and housing numbers


  • Please log in to reply
61 replies to this topic

#51 jd lj

jd lj

    Forum Fixture

  • Members
  • PipPipPipPipPip
  • 2,099 posts
  • Name:James D
  • Location:in the shed
  • Car:LJ SVO
  • Joined: 03-December 10

Posted 07 October 2015 - 06:49 PM

Whoops too many 3's getting pressed. I'll blame my phone for that, it couldn't possibly be my mistake. Lol

#52 _Michael Kononen_

_Michael Kononen_
  • Guests

Posted 09 October 2015 - 01:30 PM

cheers guys i know torri not an xu1 ,but thought it had a xu1 diff in her all good thanks again.mick



#53 _nolindsxu1_

_nolindsxu1_
  • Guests

Posted 15 November 2017 - 07:02 PM

Attached File  file-9.jpeg   184.35K   10 downloadsAttached File  IMG_20171115_185035_312.JPG   161.34K   10 downloads
Hi can anybody help decode the numbers no this diff. Hopefully fits late 71 LC s

#54 grumpy xu1

grumpy xu1

    Lotsa Posts!

  • Members
  • PipPipPipPipPipPip
  • 2,809 posts
  • Name:Gary
  • Location:Queensland
  • Car:lj xu1
  • Joined: 01-February 10

Posted 15 November 2017 - 07:22 PM

Hi can anybody help decode the numbers no this diff. Hopefully fits late 71 LC s


Yeah late lc !

09/12/71

#55 _nolindsxu1_

_nolindsxu1_
  • Guests

Posted 15 November 2017 - 08:24 PM

Thanks Gary

#56 S pack

S pack

    Scrivet Counter

  • Members
  • PipPipPipPipPipPipPip
  • 15,522 posts
  • Name:Dave
  • Location:Luggage Point
  • Car:73 LJ
  • Joined: 25-January 10

Posted 15 November 2017 - 08:57 PM

Hi can anybody help decode the numbers no this diff. Hopefully fits late 71 LC s

will also suit early 72 LJ's



#57 grumpy xu1

grumpy xu1

    Lotsa Posts!

  • Members
  • PipPipPipPipPipPip
  • 2,809 posts
  • Name:Gary
  • Location:Queensland
  • Car:lj xu1
  • Joined: 01-February 10

Posted 15 November 2017 - 09:06 PM

All good mate

#58 _nolindsxu1_

_nolindsxu1_
  • Guests

Posted 16 November 2017 - 08:29 PM

Thanks, it's on 12/71 LC , unrestored.

#59 jd lj

jd lj

    Forum Fixture

  • Members
  • PipPipPipPipPip
  • 2,099 posts
  • Name:James D
  • Location:in the shed
  • Car:LJ SVO
  • Joined: 03-December 10

Posted 20 March 2019 - 06:19 PM

I was under the Torana the other day and thought I'd look for the diff housing code while I was there. After a bit of scrubbing I found the code 2809_ _ TA. I've read this thread previously and was sure I hadn't seen any codes with TA in them. The last couple of numbers I couldn't make out at the time.
I believe that the diff housing isn't the original one for my car because I have a receipt from when the previous owner bought a diff housing while preparing the car for racing.
I know it has baffled axle tubes but don't know if these are original or not and it's currently running a 3.36 fine spline lsd.
While I'm at it does anyone know what would be the correct code for a 3.08 coarse spline lsd in a 7/73 lj s model.
JD


I know that I'm digging up an thread but I just saw this old photo on my phone and thought that I should post it here.

https://www.flickr.c...2478@N02/3xC09k

#60 Bigfella237

Bigfella237

    Socially Distant

  • Members
  • PipPipPipPipPipPipPip
  • 4,363 posts
  • Name:Andrew
  • Location:Far South Coast of NSW
  • Car:(s) not as many as I'd like but more than I've got space for!
  • Joined: 31-October 14

Posted 20 March 2019 - 10:22 PM

No good...






#61 _Mike73_

_Mike73_
  • Guests

Posted 30 March 2019 - 01:32 AM

My car was built with a 3:08 lsd, but later fitted with a 3.36 fine spline lsd with baffles and after disassembling it the other day they are definitely not factory baffles. So I believe that the entire diff housing was exchanged in preparation for racing as I have receipts for an entire housing with the centre and axles.
If you got a baffled housing with a lsd from the factory then why would anyone have taken that housing out and then fitted this one with ugly welds on the baffles when they could've just swapped the axles and the centre?

So there should be non baffled lsd housing codes also.

Hello JD To clarify things for you, The whole housing must normally be changed. To fit a 3.36 centre into a 3.08 housing would be an easier modification than the other way, if a stud and large big end nuts are used for one of the bottom fixings.

I have modified a couple of 3.36 housings to make the 3.08 fit, but this is not something that the average person would do.



Housings for 3.9, 3.55, 3.36 are the same depending if baffled or not. ( of course paint codes will differ ) they are listed separately in the parts book.

The 3.08 and 2.78 use the same housings, depending on Baffled or not. Paint codes are XM or what ever it is for a 2.78 baffled ( WX is not a code by official sources )

3.08 and 2.78 non baffled I have shown at the beginning of this thread.





The "Ugly" braze welding can be explained by heat transfer properties, i.e. the housing would need much pre-eating in order to reach the temperature to make the bronze flow, and by then the dispersed heat would make the bronze flow in a larger pattern than if thin metals were being brazed.

Mike



#62 _Mike73_

_Mike73_
  • Guests

Posted 30 March 2019 - 01:42 AM

attachicon.gif file-9.jpegattachicon.gifIMG_20171115_185035_312.JPG
Hi can anybody help decode the numbers no this diff. Hopefully fits late 71 LC s

Hello,

At the beginning of this thread I have shown that this is a 2.78 course spline housing, ( TF code as I recall ) this would be course spline, non baffled and likely to have been fitted behind a Trimatic auto with a white gearbox speedo driven gear fitted.  This would be from  S model 2 door or S or SL 4 door models.
